HeiServo Welding Machine hmanga siam a niresistance welding lama hmasawnna nasa tak a ni. Traditional pneumatic equipment ang lo takin, servo motor leh ball screw hmanga closed-loop system hmangin electrode pressing process digital control a nei thei a ni. He "electric-over-pneumatic" driving method hian complex plate (aluminum leh galvanized sheet ang chi)-a pressure nghet lo leh weld consistency tha lo industry pain point chu a tifel vek a ni.
Technical lama hlawkna bulpui ber berte
Digital Pressure Curve hmanga siam a ni
Servo drive hian pressure curve chu free setting a phalsak a, electrode pressure chu 1 kN – 10 kN chhungah chiang taka siam theih a ni.
1000 Hz MFDC Current Control a ni
built-in MFDC welding power supply hian current output accuracy ±1% a nei a ni.
Micron-level atanga inthlak danglamna Resolution
17-bit high-precision encoder hmanga thuam a nih avangin position resolution chu 0.001 mm a tling.
High-speed Production Efficiency a nei tha hle
Optimized single-point welding cycle chu 0.5 s vel chauh a ni.
Material inmil leh hman dan tur
ChumiServo Welding Machine hmanga siam a nihi high-demand sector hrang hranga versatility atana engineer a ni:
| Carbon Steel hmanga siam a ni | Q235, Q345, SPCC (0.5 mm – 3 mm) te a ni. |
| Stainless Steel hmanga siam a ni | SUS304, SUS301, SUS430 (0.4 mm – 2.5 mm) te a ni. |
| Aluminium Alloy hmanga siam a ni | 5052, 6061, 6063 (0.8 mm – 2 mm) te a ni. |
| Copper Alloys hmanga siam a ni | T2 Dar, C11000, C26000 Dar (0.5 mm – 2 mm) te a ni. |
Industry lama hman tur hrang hrang
Automotive Parts te pawh a awm bawk
Seat frame, seat belt bracket, leh kawngkhar tihchakna te a awm bawk.
EV Battery leh a dahna tur a ni
Battery tabs, module structure hrang hrang, lehBusbar chuan a rawn ti aconnection hrang hrang a awm.
Electric leh Hardware lam thil a ni
Copper bar, terminal, hinge, leh thir frame te a awm bawk.
Customer Value: Khawvel harsatna tak tak-Solution
Weld Spatter tihbo rawh
Programmable pressure curve hmang hian squeeze leh welding phase te chu i optimize thei a, chu chuan pressure tlahniam nghal emaw current tam lutuk avanga expulsions te chu a veng thei a ni.
Quality Traceability a awm bawk
Optional displacement monitoring system (0.01 mm accuracy) hmang hian weld pakhat zel "nugget collapse" chu i track thei ang. He data hian weld hian a mamawh thuk zawng a thleng tih 100% verification a pe a ni.
Maintenance Cost tihhniam a ni
Precision water cooling (10℃– 30℃) leh controlled impact force te hian i CuCrZr electrode te dam chhung nasa takin a ti rei a, dressing leh replacement frequency a ti tlem a ni.
Certification pek chhuah a ni
Khawvel pumah customer 5,000+ chuang kan rawng kan bawl tawh a, hun rei tak-kan thawhpui te zingah hian Tesla, BYD, leh Siemens te pawh an tel.
50+ aia tam Fortune 500 company te an ni.
Kan Partner te
40+ Patents leh National Software Copyright 2, 10,000m Factory ah 100+ hnathawk thiam tak tak awmna.
Engvangin Nge Kan Partnerpui?
Core-ah hian Intelligence a awm
Kan PLC-based control system hian welding program set 30–100 a dahkhawm a, hei hian workpiece hrang hrang inkara inthlak danglamna rang tak a siam thei a ni.
Full Automation a awm tawh
Standard I/O interface leh automatic fixture atana 0.5–0.7 MPa air supply hmanga thuam kan machine te hi robotic cell-a awlsam taka inzawmkhawm thei tura siam a ni.
Efficiency tih finfiah a ni
Kan transformer te hi 90%–95% efficiency-in an thawk a, chu chuan i energy senso chu a hniam reng laiin output a sang reng tih a tichiang a ni.
FAQ
01.He Servo Welding Machine hian copper ang chi high{1}}conductivity materials a handle thei em?
02.Engtin nge weld chak lo (cold weld) ka ven theih ang?
03.Tui lumna system hi tih ngei ngei tur a ni em?
04.Ball screw hi engzat nge maintenance a mamawh?
05.Production laiin weld a chhiat chuan ka detect thei ang em?
